Lotus 1" Mini Puck Recessed Lighting 6-Pack Kit – 4000K 1W 12V DC | 6P-AD108-4K-D-H

Overview

The Lotus LED AD-108 6-Pack is a comprehensive architectural-spec kit designed for precision recessed lighting in cabinetry, displays, and niche applications. This low-voltage system provides a complete plug-and-play solution, featuring six ultra-compact 1-inch mini pucks, a 6-port hub, and a dedicated plug-in driver for streamlined installation.

Key Features

• Full contractor-grade kit includes 6 mini puck lights, a 6-port hub, and a 12V DC plug-in driver.
• Exceptional color accuracy with a CRI of 90+ for high-end display environments.
• Ultra-low profile design with a 5/8-inch depth ideal for shallow shelving and soffits.
• Air-tight construction and approved for damp locations to ensure long-term durability.
• Efficient 1W LED performance delivering crisp 4000K cool white illumination.

Technical Specifications

• Energy Used: 1W per puck
• Halogen Equivalent: 5W
• Light Output: 80 lm
• Color Temperature: 4000K
• CRI: 90+
• Beam Angle: 100°
• Input Voltage: 12V DC (Pucks) / 120V AC (Plug-in Driver)
• Fixture Dimensions: 1" ID, 1 5/16" OD, 5/8" Depth
• Cutout: 1 1/16"
• Approved Location: Damp Locations
• Air Tight: Yes
• Projected Life: 70% light output at 50,000 hours
• Certification: cETLus
• Driver: Non-dimmable plug-in driver included (Model WLS-PD30LU-24)
• Daisy Chain Capability: Connect up to 10 puck lights to the included driver
• Warranty: 3 Year
