Lotus 8" Round Slim Recessed LED 33W | LY82RCD

Overview

The Lotus LED LY82RCD is a contractor-grade 8-inch round slim recessed light designed for high-output applications where ceiling space is limited. At only 1 3/4 inches deep, this architectural-spec fixture features an integral driver inside a connection box, eliminating the need for traditional recessed housing in both insulated and non-insulated ceilings.

Key Features

• Ultra-slim 1 3/4-inch profile allows for installation in tight plenums and directly under joists.
• Type IC Rated for safe, direct contact with insulation without requiring a separate housing.
• High-performance dimmable driver provides smooth 10% to 100% dimming with standard TRIAC dimmers.
• Wet Location and Air-Tight certified, making it suitable for both indoor and outdoor architectural applications.
• Durable die-cast aluminum alloy body with a scratch-resistant finish for optimal heat dissipation and longevity.

Technical Specifications

• Wattage: 33W
• Light Output: 2200 lm (3000K) | 2400 lm (4100K)
• Halogen Equivalent: 200W
• Beam Angle: 110°
• CRI: 80+
• Input Voltage: 120V AC (Optional 277V-347V AC)
• Power Factor: 0.98
• Projected Life: 70% light output at 50,000 hours
• Operating Temperature: -40°F (-40°C) to +104°F (+40°C)
• Dimensions: ID 7 1/4"; OD 9"; Cutout 7 1/2" to 8"
• Clearance Required: 1 3/4" above ceiling
• IP Rating: IP 54 (Wet Locations)
• Compliance: cULus, Energy Star, T24
• Warranty: 10 Year Residential | 5 Year Commercial
